Caterpillar MH3024

Description

Caterpillar MH3024 – High-Performance Material Handler for Scrap, Waste, and Industrial Handling

The Caterpillar MH3024 is a purpose-built material handler designed for fast, efficient, and reliable material movement in industries such as scrap recycling, waste handling, port operations, and industrial loading. With a reinforced structure, powerful hydraulics, and excellent reach capabilities, the MH3024 is engineered to deliver high productivity while keeping fuel and maintenance costs under control.

This model combines Caterpillar’s trusted durability with advanced design features that make it ideal for both stationary yard work and high-mobility job sites.

---

Key Features of the Caterpillar MH3024

Purpose-Built Design
Unlike converted excavators, the MH3024 is specifically designed for material handling tasks. It features a heavy-duty upper frame, reinforced boom and stick, and a raised, hydraulically elevating cab for optimal visibility and control during operations.

Powerful and Efficient Cat Engine
The MH3024 is equipped with a Cat engine that offers excellent fuel efficiency, low emissions, and the power required for continuous loading, sorting, and lifting cycles.

• Engine Power: Approximately 174 hp (129 kW)

• Emissions: Meets Tier 4 Final / EU Stage IV standards (regional availability may vary)

• Auto-idle and eco-modes to reduce fuel consumption during low-demand tasks

Advanced Hydraulics
The hydraulic system is engineered for fast, smooth operation, allowing for high precision and shorter cycle times. Load-sensing hydraulics ensure that power is delivered where and when it is needed, without unnecessary fuel usage.

Elevated Operator Station
Visibility is critical in material handling applications. The MH3024 features a factory-installed elevating cab that gives the operator a clear view over large stockpiles, containers, or railcars. The cab is also fully pressurized for comfort and safety.

Multiple Attachment Options
The MH3024 is compatible with a wide range of attachments, including:

• Orange peel grapples

• Sorting grabs

• Clamshell buckets

• Magnets (with optional generator)

Quick coupler systems allow for fast switching between tools, enhancing versatility on site.

---

Specifications of the Caterpillar MH3024

• Operating Weight: Approximately 23,000 – 25,000 kg

• Engine Power: 174 hp / 129 kW

• Max Reach (Horizontal): Up to 11 – 13 meters (varies by configuration)

• Max Lifting Capacity: Approximately 3.5 – 4.5 tons at max reach

• Undercarriage: Wheeled base with outriggers and front blade (configurable)

• Cab Elevation Height: Up to 5.6 meters (eye level)

---

Applications

The Caterpillar MH3024 is ideal for:

• Scrap metal recycling

• Waste transfer stations

• Sorting and stockpiling

• Port and dock material handling

• Rail yard operations

• Timber and forestry yards

Its balanced size and performance make it especially effective in medium-sized yards and facilities where mobility and reach are critical.

---

Benefits of the Caterpillar MH3024

• Specifically built for material handling — not a modified excavator

• Fuel-efficient operation with intelligent hydraulic control

• Elevated cab improves job site visibility and safety

• Strong resale value in both local and international markets

• Reliable Cat support and global parts availability

---

Conclusion

The Caterpillar MH3024 is a highly capable, purpose-built material handler that brings together performance, visibility, efficiency, and durability in one well-balanced machine. Whether you’re handling scrap, waste, logs, or bulk materials, the MH3024 is designed to keep your operation moving safely and productively.

For businesses looking to invest in a reliable, export-ready material handler, the Cat MH3024 offers excellent long-term value and operational efficiency across multiple industries.
